COMMERCIAL MMIC PRODUCTS
GaN Power Amplifier MMIC Die
Power amplifier MMICs designed for narrow and broadband applications with a focus on E and W band.
Packaged Amplifiers
HRL can package our in-house MMIC amplifiers in split block housings that cover E and W band.
Multi-Chip Modules
HRL has the capability to design custom MCMs to fit specific customer needs.
| Part # (Datasheet) |
Function | Frequency (GHz) | Psat (dBm) | Lin Gain (dB) | Peak PAE (%) | DATA | CAD FILES |
|---|---|---|---|---|---|---|---|
| BAL-WPA-T3L (New) |
Broadband Power Amplifier | 70-105 | Coming soon… | Coming soon… | Coming soon… | Coming soon… | .gds |
| G94-PA-T3L (New) |
Power Amplifier | 90-95 | Coming soon… | Coming soon… | Coming soon… | Coming soon… | .gds |
| BAL-WPA (Discontinued) |
Broadband Power Amplifier | 70-105 | 20 | 15 | 11 | s-param | .gds |
| G94-PA (Discontinued) |
Power Amplifier | 90-95 | 27 | 16 | 16 | s-param | .gds |
| G84-PA (Discontinued) |
Power Amplifier | 80-86 | 27 | 16 | 16 | s-param | .gds |
| G74-PA (Discontinued) |
Power Amplifier | 68-76 | 27 | 16 | 16 | s-param | .gds |
HRL’s commercial GaN MMIC offerings include a 94 GHz narrow-band PA and a broadband 70–105 GHz PA designed for demanding E-band and W-band applications. Both products are fabricated in HRL’s T3L GaN technology, a state-of-the-art mm-wave GaN process delivering exceptional power density, efficiency, and reliability at frequencies at W-band.
We are actively expanding our T3L-based product family with upcoming high-power amplifiers, LNAs, and advanced mmW components.
In addition to catalog products, HRL provides custom GaN MMIC design services, including tailored LNAs, PAs, mixers, switches, and transceiver components. HRL also develops custom multifunction modules and is preparing to introduce packaged versions of our commercial MMICs.
HRL’s engineering capabilities extend to wafer-level packaging, high-performance module and subsystem integration, and the development of complete microwave/mmW assemblies.
Items are subject to U.S. Government export control laws and regulations including 15 CFR Parts 730–774 (Export Administration Regulations) and may require a license for export, re-export or retransfer.
For technical inquiries or custom MMIC discussions, please contact mmics[at]hrl.com
